The VAMP (ValvACT Actuator Mounted Power) system is an actuator mounted hydraulic power pack designed for quarter-turn actuators. It can be supplied with Eckart HyRAV SG hydraulic actuators for reliable performance with both dual-acting and spring-return, fail-safe options. Additionally, VAMP can be applied to similarly styled hydraulic actuators from other manufacturers.
The VAMP system operates the actuators using a hydraulic pump that can be driven off 24V DC, single-phase AC, or three-phase AC power sources in addition to pneumatic pressure as low as 60 psi.
The VAMP system is well suited for austere hazardous locations due to its low voltage DC power,
hydraulic load holding, and fail-safe capability. To facilitate these isolated applications, users may wish to
integrate solar panel packages that remove the need for generators or grid power for reliable valve
control. Additionally, VAMP can be operated using an integrated hand pump or by attaching an external
pump to the quick-disconnect ports in the event of power loss.
Check out the VAMP Electrohydraulic Actuator Prototype Function Demonstration below!
ADVANTAGES:
- Designed for ready adaptability to new and existing valves or connection to existing actuators.
- Easy integration with Eckart hydraulic double-acting and spring-return actuators.
- Wide variety of input power source options including low voltage DC, AC, and pneumatic.
- Choice of environmental ratings between Class I Division 1 Groups C&D or NEMA 4X.
- Easy and safe control of actuator speed – Opening and closing speed are set independently using hydraulic flow control valves.
- Independent opening and closing speed allow rapid operation to fail-safe position.
- Manual operation with hydraulic handpump or integrated quick-disconnect ports.
- SAE-4 ports on all models for quick-disconnect fittings or gauges to be added – readily adapted to customer desired standard.
- Separate junction box allows field connections to be made without exposing internal controls to dangerous environmental conditions.
- Local control available through a Remote/Off/Local and Open/-/Close switch
- Communication and control over Modbus or 24V signal wires.
- Optional remote throttling with 4-20 mA analog position control and feedback.
- VAMP can be controlled remotely using Open/Close and Run/Stop signals or by transmitting a position set point which the actuator will move the valve toward and hold.
- Capable of restoring commanded position in the event of power or pressure loss.
- Integrated controller continuously monitors system operation with alarms for:
– Position sensor signal rationality.
– Excessive position error (valve position is too far from set point).
– Maximum and minimum stroke time.
– Motor protection duty cycle.
– Motor or motor controller over-temperature fault.
– Loss of position command signal.
– Local control override.
ValvACT is the sole North American agent and distributor for Pleiger Maschinenbau-GmBH.
ValvACT is the only U.S. distributor of the HyRAV Series Hydraulic Valve Actuator.
CONTACT US for more information.
